Tacos 4KTQ I0vt Swap: The Red Baron - buying parts again

AngryTaco · Post by **AngryTaco** » Tue Sep 17, 2013 5:17 pm

I needz moar efficient boost

DE80q · Post by **DE80q** » Tue Sep 17, 2013 7:01 pm

scubadave wrote:Hey now, love the turbo...but don't loooovve the turbo. Mkay?

I was thinking the same thing!

scubadave · Post by **scubadave** » Tue Sep 17, 2013 7:32 pm

I tried to put up the robot chicken humping robot gif but can't make it work on my phone.

Edit...nevermind, fixed it with my tablet.

scubadave · Post by **scubadave** » Wed Sep 18, 2013 11:31 am

: ludicrous-speed1802781069.png (363.25 KiB) Viewed 26887 times

AngryTaco · Post by **AngryTaco** » Wed Sep 18, 2013 4:48 pm

MAH TERBOZ HAZ ARRIVEZZZDDDD!!!!!!

scubadave · Post by **scubadave** » Wed Sep 18, 2013 4:54 pm

Is it running yet!?

AngryTaco · Post by **AngryTaco** » Wed Sep 18, 2013 6:45 pm

It depends on how I feel honestly. I might do it before I drive down to Bens place in a couple weeks for our epic pre-bbq weekend

chaloux · Post by **chaloux** » Wed Sep 18, 2013 9:11 pm

Do it or... I dunno. I guess don't.

lol

DO IEEEET. I need another red 4ktq to look at. One that fakin works

AngryTaco · Post by **AngryTaco** » Wed Sep 18, 2013 11:00 pm

Lol. I decided if I have all the parts by Friday, Ill do it this weekend

my2000apb · Post by **my2000apb** » Thu Sep 19, 2013 10:20 am

diff en route

AngryTaco · Post by **AngryTaco** » Thu Sep 19, 2013 10:51 am

Yay!!! Going 3.89s beotches. Damn you Dan!

ERMAHGERD MAH PORSCHE TERBOZ PARTS ARRIVEZZZZ TODAYZ!!

DE80q · Post by **DE80q** » Thu Sep 19, 2013 11:04 am

Good, now get them all put together and installed! Im sure it wont take you too long. :beer:

GTJeff · Post by **GTJeff** » Thu Sep 19, 2013 1:12 pm

Wouldnt the first thing be to take the wbo2 out of the truck and stick it in the 4k......?

AngryTaco · Post by **AngryTaco** » Thu Sep 19, 2013 2:48 pm

Youve been talking to ben havent you?

Lol. Im working on it

85oceanic · Post by **85oceanic** » Thu Sep 19, 2013 5:57 pm

GTJeff wrote:Wouldnt the first thing be to take the wbo2 out of the truck and stick it in the 4k......?

No freaking joke. :guns:

AngryTaco · Post by **AngryTaco** » Thu Sep 19, 2013 11:15 pm

Who needs a wideband when you have a narrowband and a natrix chipped ecm?!

AngryTaco · Post by **AngryTaco** » Thu Sep 19, 2013 11:40 pm

So finally got everything in. As requested, I have posted the following pictures showing the difference between the modified audi k24 housing and a stock porsche K26 #6 hotside. It's quite noticeable really.

Here it is in all its shiny glory after I mated it to the porsche K26 housing

Porsche K26 exit bore diameter

Porsche K26 entry diameter

Modified Audi K24 Exit Diameter

Modified Audi K24 entry diameter

Porsche K26 Entry Way

Audi K24 Entry Way

It's really hard to tell from the last 2 pictures, but the Porsche K26 has a much larger runner going into the turbo housing. Me and scubadave believe this is a good reason to his detonation issues. The exit diameter on the Porsche k26 is a MUCH better fit with its 50.00mm diameter. I'm honestly not sure what that will change over the 51.xx mm exit diameter of the modified Audi K24. Perhaps a reduction in turbulence????

All I know is I'm going to polish what I can on the inside of the porsche hotside and enjoy the hell out of this turbo.

scubadave · Post by **scubadave** » Fri Sep 20, 2013 12:31 am

My name is Scubadave and I approve this message.

AngryTaco · Post by **AngryTaco** » Fri Sep 20, 2013 11:09 pm

Ugh. Had a fight with the CIS tonight. Fired it uo after 2 weeks of sitting and it did NOT want to idle. After backing out the idle adjustment screw, it finally idled. I dont get it. 2 weeks ago it was fine. I do know there is something wrong with the fuel system. I hooked up a pressurr gauge between the WUR and the fuek distributor and measured the fuel psi after shutting the car off. It idl es at 55-60psi which is normal. Then upon shutdown it immediately drops to 15psi. Its only supposed to drop to 45psi after 10 minutes. Where the hell is my fuel going?! Ugh I am so ready for VEMS

Im highly suspecting the WUR committed suicide by boredom. I have a couple extras and all signs have been pointing to it, so Ill change it this weekend

85oceanic · Post by **85oceanic** » Sat Sep 21, 2013 11:52 am

Couldn't a bad FPR be the culprit too?

AngryTaco · Post by **AngryTaco** » Sat Sep 21, 2013 12:03 pm

The WUR is a fpr. Its real name is control pressure reg

themagellan · Post by **themagellan** » Sat Sep 21, 2013 1:33 pm

AngryTaco wrote:Ugh. Had a fight with the CIS tonight. Fired it uo after 2 weeks of sitting and it did NOT want to idle. After backing out the idle adjustment screw, it finally idled. I dont get it. 2 weeks ago it was fine. I do know there is something wrong with the fuel system. I hooked up a pressurr gauge between the WUR and the fuek distributor and measured the fuel psi after shutting the car off. It idl es at 55-60psi which is normal. Then upon shutdown it immediately drops to 15psi. Its only supposed to drop to 45psi after 10 minutes. Where the hell is my fuel going?! Ugh I am so ready for VEMS

Im highly suspecting the WUR committed suicide by boredom. I have a couple extras and all signs have been pointing to it, so Ill change it this weekend

Mr. Taco - I had a similar issue on my 87 Fox with CIS - I ended up ripping off the CIS for a 32/36 carb but I realized when I pulled the injectors off it was simply that the injectors had some crud in them (Most noticeably in the Cold Start Injector) Give those bad boys a nice brake cleaner batch and check those lines.

AngryTaco · Post by **AngryTaco** » Sat Sep 21, 2013 5:27 pm

YeH thats a good idea. I was going to buy a harbor freight ultrasonic clearing machine and soak them in seafoam

DE80q · Post by **DE80q** » Sat Sep 21, 2013 5:46 pm

Well, another CIS problem. Dont know about you, but I dont forsee the current fuel system keeping up the the Volvo K24. I could be wrong though.

Dont know if you noticed, but there is a set of 550cc injectors for sale in the swap meet. hint...hint...

themagellan · Post by **themagellan** » Sat Sep 21, 2013 7:48 pm

DE80q wrote:Well, another CIS problem. Dont know about you, but I dont forsee the current fuel system keeping up the the Volvo K24. I could be wrong though.

Dont know if you noticed, but there is a set of 550cc injectors for sale in the swap meet. hint...hint...

A volvo CIS unit is very cheap as well with a one or two extra Injectors along the way:) - search alaincopter on vwvortex for some CIS inspiration.
